HARDWARE SPECIFICATIONS
|
|
|
CPU
|
AMLogic S905-H Quad Core up to 2.0 GHz
|
|
GPU
|
Mali MP-450 Penta core
|
|
Memory
|
1 GB DDR3 1333MHz
|
|
Flash
|
8GB eMMC
|
|
WIFI
|
Built-in 2.4/5 GHz WiFi 802.11 B/G/N/AC
|
|
|
|
|
POWER SUPPLY
|
|
|
Power Supply(Adapter)
|
DC 12V/2A
|
|
Power Indicator (LED)
|
Power “On”: Blue / Standby: Red
|
|
|
|
|
MAIN FEATURES
|
|
|
Stream Support
|
RTSP, RTP, HTTP, UDP, IGMP etc.
|
|
DRM
|
Google Widevine, HDCP 2.2, Secure OS 2.0
|
|
Video Processing
|
H264, H265 up to 4k@60Hz
|
|
Video Codecs
|
H.265, H.264 AVC, H.264, MVC, MPEG-1,MPEG-2 SD/HD
|
|
|
MPEG-4 SD/HD, ASP, VC-1/WMV, AVS/AVS+, MJPEG, HEVC HD, UHD
|
|
Video Containers
|
MKV, WMV, MPG, MPEG, DAT, AVI, MOV, ISO, MP4, RM and JPG
|
|
Audio Codecs
|
MPEG 2 Audio, AAC, MP3, WMA, RM, FLAC, OGG MP3, AAC, WMA
|
|
|
RM, FLAC, Ogg, Dolby Digital, Dolby Digital Plus, DTS
|
|
HD video output
|
Ultra HD max. 3840×2160 pixels
|
|
|
|
|
AUDIO OUT
|
|
|
Digital-to-Analog Converter
|
192kHz/24-bit
|
|
Digital audio output
|
HDMI
|
|
|
|
|
VIDEO OUT
|
|
|
Video output signal
|
NTSC and PAL TV system
|
|
Analog video output
|
CVBS
|
|
Digital video output
|
HDMI
|
|
|
|
|
PRODUCT SPECIFICATIONS
|
|
|
Length
|
115mm / 4.52in
|
|
Width
|
109mm / 4.29in
|
|
Height
|
25mm / 0.98in
|
|
|
|
|
OPERATING SYSTEM
|
|
|
ZaapTV™ OS based on Android 5.1.1
|
|
|
|
|
|
CONNECTIVITY
|
|
|
2x USB Socket
|
|
|
1x Audio/Video analog output
|
|
|
1x HDMI 2.0 Socket
|
|
|
1x LAN Gigabit 1000Mbit/s
|
|
|
1x MicroSD Card Slot
|
|
|
Built-in WIFI
|
|
|
|
|
|
OTHER
|
|
|
1x 12V DC Input Jack
|
|
|
Power Switch
|
|
|
Remote Receiver
|
|
|
Power LED
|
|
|
|
|
|
ACCESSORIES
|
|
|
Instruction Manual
|
|
|
110V/220V PSU US/EU/UK/AU Plug
|
|
|
Bluetooth Remote
|
|
|
|
|
|
CERTIFICATIONS
|
|
|
CE, FCC, RoHS
|
